Rapidox 2100 Stainless Probe

For rugged industrial oven applications, Cambridge Sensotec has a range of special stainless measurement probes for insertion into a hot atmosphere through a thick wall of an oven.

The zirconia sensor is housed in a specially constructed stainless sheath with the sensor tip housed in a recessed end housing for protection. The probe is 50cm long and is either welded to a standard size DN / ANSI flange or mounted onto a sample port using a KF50 flange and clamp system.

The mounting point is therefore completely gas-tight and the clamp allows quick release of the probe for service and calibration. A blanking cap is provided for closure when the probe is not in position.

The sensor can be connected to a standard R2100 or an OEM system via a rugged armoured cable that can be made in lengths up to 25m depending on the customers’ exact requirement.
